Targus Universal Docking Station Supported Resolutions
August 07, 17
- Posted in: Tech Talk by Kevin Quinn, Thee DocKtor
If the host's graphics support it, Targus Universal Docking Stations support the display monitor resolutions indicated in the following chart. These are only a subset of the resolutions supported; called the most met resolutions, but resolutions in between these are also supported.
| Resolution (Pixels) | Name (VESA) | Refresh Rate (Hz) | ACP70 / ACP71 DOCK110 DOCK120 DOCK520 |
ACP77 DOCK150 |
DOCK130 DOCK410 |
DOCK160 DOCK177 DOCK180 DOCK190 DOCK220 |
|---|---|---|---|---|---|---|
| 640x480 | VGA | 60 67 72 75 85 | Available | Available | Available | Available |
| 720x400* | 70 85 88 | Available | Available | Available | Available | |
| 720x480 | 50 60 | Available | Available | Available | Available | |
| 768x576 | 50 60 | Available | Available | Available | Available | |
| 800x600 | SVGA | 56 60 72 75 85 | Available | Available | Available | Available |
| 832x624 | 75 | Available | Available | Available | Available | |
| 800x480 | 60 | Available | Available | Available | Available | |
| 848x480 | 60 | Available | Available | Available | Available | |
| 1024x600 | 60 | Available | Available | Available | Available | |
| 1024x768 | XGA | 60 70 75 85 | Available | Available | Available | Available |
| 1152x864 | 75 | Available | Available | Available | Available | |
| 1152x870 | 75 | Available | Available | Available | Available | |
| 1280x720 | 720p | 50 60 | Available | Available | Available | Available |
| 1280x768 | WXGA+ | 60 75 85 | Available | Available | Available | Available |
| 1280x800 | WXGA | 60 | Available | Available | Available | Available |
| 1280x960 | 60 85 | Available | Available | Available | Available | |
| 1280x1024 | SXGA | 60 75 | Available | Available | Available | Available |
| 1360x768 | 60 | Available | Available | Available | Available | |
| 1366x768 | WXGA+ | 50 60 | Available | Available | Available | Not Applicable |
| 1368x768 | 60 | Available | Available | Available | Available | |
| 1400x1050 | SXGA+ | 60 75 85 | Available | Available | Available | Available |
| 1440x900 | 60 | Available | Available | Available | Available | |
| 1600x900 | 60 | Available | Available | Available | Available | |
| 1600x1200 | UXGA | 60 | Available | Available | Available | Available |
| 1680x1050 | WSXGA+ | 60 | Available | Available | Available | Available |
| 1920x1080 | 1080p | 50 60 | Available | Available | Available | Available |
| 1920x1200 | WUXGA | 60 | Available | Available | Available | Available |
| 2048x1080 | 2K | 60 | Available | Available | Available | Available |
| 2048x1152 | 60 | Available | Available | Available | Available | |
| 2048x1280 | 60 | Available† † | Available* | Available† † | Available | |
| 2048x1536 | 60 | Available† † | Available* | Available† † | Available | |
| 2560x1440 | 50 | Available† † | Available* | Available† † | Available | |
| 2560x1440 | 60 | Available† † † | Available** | Available† † † | Available | |
| 2560x1600 | WQXGA | 60 | Available† † † | Available** | Available† † † | Available |
| 3440x1440 | 30 | Not Applicable | Not Applicable | Available† † † | Available | |
| 3840x2160 | UHD | 30 | Not Applicable | Not Applicable | Available† † † | Available |
| 3840x2160 | UHD | 60 | Not Applicable | Not Applicable | Not Applicable | Available |
| 4096x2160 | Cinema 4K | 60 | Not Applicable | Not Applicable | Not Applicable | Available |
| 5120x2880 | 5K | 60 | Not Applicable | Not Applicable | Not Applicable | Available |
* Only available over DisplayPort and HDMI outputs
** Only available over DisplayPort output
†† Only available over DisplayPort and HDMI outputs when using a single video output (not supported in dual-head mode)
††† Only available over DisplayPort output when using a single video output (not supported in dual-head mode)
Note: Interlaced modes are not supported.
