Targus Universal Docking Stations’ USB Charging Ports

February 10, 15 - Posted in: Tech Talk by Kevin Quinn, Thee DocKtor
Targus Universal Docking Stations’ USB Charging Ports
All of the USB Ports on TUDS supply power per the USB specification. Some are labeled (with a small lightning bolt) as fast charging per the BC 1.1/1.2 specifications, and some of these support Apple charging. Whether or not the USB devices will take power depends on the device. See the following diagrams for the specifics charging ports available by TUDS model. Note, the power switch must be on for the ports to be powered.
USB Fast "Charging" (marked) BC 1.1/1.2 USB 3.0 Charging USB 2.0 Charging
5Vdc * 1500mA = 7.5W 5Vdc * 900mA = 4.5W 5Vdc * 500mA = 2.5W
5Vdc * 1500mA = 7.5W 5Vdc * 900mA = 4.5W 5Vdc * 500mA = 2.5W
5Vdc * 1500mA = 7.5W 5Vdc * 900mA = 4.5W 5Vdc * 500mA = 2.5W
5Vdc * 1500mA = 7.5W 5Vdc * 900mA = 4.5W 5Vdc * 500mA = 2.5W

ACP70 USB Charging

ACP71 USB Charging

ACP77 USB Charging
